Project Description

6.0kW of Cooling. Full control of temperature with a full selection of accessories.

6.0kW Cooling Capacity (@17°C set point).

Versatile design, allowing for many standard and non standard options.

Totally reliable workhorse.

Key Aspects:

  • Dimensions L x W x H: 775 x 510 x 850 mm

  • Cooling capacity (water @ 17°C): 6000 watts

  • Microprocessor-based temperature controller: 3 term PID digital

  • Temperature adjustable: 0.1°C increments

  • Temperature stability +/- 0.1 °C
  • Temperature range +4° to +35°C
  • Extended temperature range – Optional -20° to +70°C
  • Digital temperature display Standard
  • Temperature alarm – Standard off-set +/- 10°C Adjustable High / Low
  • Low fluid level alarm: Standard – Visual with pump interlock
  • Auto diagnostic functions: Controller and sensor
  • System volume: 7 litres
  • Pressure control system Standard fitment internal – user adjustable between 20 and 150psi
  • Compatible fluids: Hexid fluids / water / propylene glycol
  • Fluid connections: BSP Threaded Male 3/4″, Female 1/2″, 3/8″ and 1/2″ barbs also supplied
  • Compressor over – load protection: Standard
  • Emergency Off (EMO): Via main circuit breaker (MCB)
  • Tool-less access: No
  • Noise level: 68 dB(A) @ 1 metre
  • Weight (approximated -Varies with options): 125kg
  • Wheels for mobility: Standard (2 locking)
